Inverter SR1600 Plus with 24V or 48V

  • Installation in 19″ rack 2U high
  • Designed for telecommunications applications
  • Input possible either 18-34VDC or 36-60VDC
  • Full output power
  • High efficiency, >95% (AC)
  • High power density
  • Integrated static switch
  • DSP for improved reliability and performance
  • Output 230Vac
  • Up to 32 modules can be operated in parallel

SR1600Plus Inverter with 24V or 48VDC Input

Eaton’s inverters are used in the modular inverter system for uninterruptible power supply. For a strong and highly efficient output voltage. Inverters are needed wherever generated direct current needs to be converted into alternating current, whether for the public power grid, for private consumption or for a safe and uninterruptible power supply (UPS) in hospitals, data centers or power plants of all kinds.

Environmental requirements for the inverter

  • Ambient temperature: -20°C to 60°C; -20°C to 50°C at full load
  • Storage temperature: -30°C to 80°C
  • Humidity: 95% RH
